TABER Abrasion Machine

Short Description:

This machine is suitable for cloth, paper, paint, plywood, leather, floor tile, glass, natural plastic and so on. The test method is that the rotating test material is supported by a pair of wear wheels, and the load is specified. The wear wheel is driven when the test material is rotating, so as to wear the test material. The wear loss weight is the weight difference between the test material and the test material before and after the test.


Product Detail

Product Tags

Application

This machine is suitable for cloth, paper, paint, plywood, leather, floor tile, glass, natural plastic and so on. The test method is that the rotating test material is supported by a pair of wear wheels, and the load is specified. The wear wheel is driven when the test material is rotating, so as to wear the test material. The wear loss weight is the weight difference between the test material and the test material before and after the test.

Standard: DIN-53754,53799,53109,TAPPI-T476,ASTM-D3884,ISO5470-1

The TABER Abrasion Tester, an excellent machine designed to test the abrasion resistance of materials. It is used in a wide range of applications, including abrasion tests on leather, fabric, paint, paper, floor tiles, plywood, glass and natural rubber. The following will reveal the mystery of TABER abrasion test machine for you in detail:

1. Test principle

The TABER abrasion tester works as follows: first, a standard cutter is used to cut the specimen, then a specific type of grinding wheel is selected and the specimen is subjected to a wear test under preset load conditions. During the test, the machine is operated at a specified number of revolutions. At the end of the test, the specimen is removed and the wear condition is observed, or the degree of wear is assessed by comparing the weight difference before and after the test.

Model

KS-Tb

Test piece

Inner diameter (D)3mm

Wear wheel

Phi 2 "(Max.45mm)(W)1/2"

wear wheel center spacing

63.5mm

wear wheel and test disc center spacing

37 ~ 38mm

Rotation speed

60~72r/min adjustable

Load

250,500,1000 g

counter

LED 0 ~ 999999

Distance between test piece and suction port

3mm

Volume

45×32×31cm

weight

About 20kg

Power supply

1 # AC 220V, 0.6A

Random configuration

1 wrench, 1 set of grinding wheel, weights (250g, 500g, 750g)
