Products

Spectrometer + thermal desorber

Short Description:

1, short sample time: sample time to meet the user’s rapid screening needs;

2, does not produce waste gas and liquid: no reagents, no pre-treatment, no waste gas and liquid;

3, the use of low cost: no reagents and consumables, the cost of a year within 3000 yuan;

4、Simple operation: directly into the sample, production line workers can operate after training;

5、Built-in standard curve: intuitively determine whether the material exceeds the standard (exclusive technology);

6, without professional laboratory environment: with air-conditioning power supply can be installed in the operating space;


Product Detail

Product Tags

Parametric

E8-SPR: Spectrograph

1

Instrument size:510*380*415

Measure 6:Pb,Hg,Cd,Cr,Br,Cl

KS-PYGC-97 Thermal cleavage desorber:

1 (2)

NO.

Descriptions

Quantities

Unit

1

1000ppm phthalate ester mix 4P (BBP/DEHP/DIBP/DBP)

1

Bottle

Product Performance Parameters

Py/TD part (fully meets the requirements of IEC 62321-8:2017):

Item

Performance indicators

Temperature range 5℃ - 500℃ above room temperature
Temperature control precision Temperature control accuracy ±0.2℃ for target compounds
Temperature rise rate ≤200℃/min
Resolution temperature control Programmed temperature control
Purging Flow Rate 0-500mL/min
Interface Temperature Range 5℃ - 400℃ above room temperature
GC section:
Inlet Temperature Range Above room temperature 5℃-350℃
Inlet Type Shunt/no shunt
Column Temperature Range Above room temperature 5℃~450℃, increment: 0.5℃; precision: ±0.1℃.
Temperature Steps Can achieve 16-step programme temperature rise
Other Features 1, the use of technologically advanced 100 megabit / Gigabit Ethernet communication interface and built-in IP stack, so that the instrument can be achieved through the internal LAN, the Internet to achieve long-distance data transmission; easy to set up the laboratory, simplify the configuration of the laboratory, and convenient to analyse the management of data.

2, the instrument is equipped with 7-inch colour LCD touch screen, support hot-swappable, can be used as a handheld controller.

3, the instrument uses a multiprocessor parallel mode of operation, making the instrument more stable and reliable; optional high-performance detectors, such as FID, TCD, ECD, FPD and NPD, can be installed at the same time up to three detectors, FID detection with automatic ignition function.

4、Using low-noise, high-resolution 24-bit AD circuit, with baseline storage, baseline deduction function.

List of commonly used consumables and some breakdown

No.

Item

Remarks

1 4-item o-benzene standard solution 8 ml/bottle
2 Quartz sample boat Re-use each sample cup 10 times
3 Quartz cracking furnace Replacement according to sample volume
4 Quartz injection tube Replacement according to the sample volume
5 Non-polar capillary column Imported chromatographic columns, according to the sampling conditions, about 2 years to replace the
6 Manual injection needle National brand
7 Nitrogen Purity of 99.999% or above, find a local gas supplier for replacement.
