Automatic Rupture Strength Tester
Automatic Bursting Strength Tester：
Automatic Carton Rupture Strength Tester is a device designed for testing the rupture strength of cartons and other packaging materials. It helps companies and individuals to efficiently and accurately assess the rupture resistance of cartons or other packaging materials to ensure their safety during transport and storage.
The testing process is as follows:
1. Prepare the sample: Place the carton or other packaging material to be tested on the test platform to ensure that the sample remains stable and not easy to slide during the test.
2. Setting test parameters: according to the test requirements, set the test force, test speed, test times and other parameters.
3. Start the test: Switch on the device and make the test platform exert pressure on the sample. The device will automatically record and display data such as the maximum force and the number of ruptures that the sample is subjected to. 4.
4. End Test: When the test is completed, the device will automatically stop and display the test results. According to the result, evaluate whether the rupture strength of the packaged product meets the standard or not.
5. Data processing and analysis: collate the test results into a report, analyse the data in depth and provide reference for the optimization of packaging products.
Automatic carton rupture strength tester plays an important role in ensuring packaging safety and improving product quality, providing reliable packaging solutions for various industries.
| Model | KS-Z25 |
| Display | LCD |
| Unit conversion | kg、LB、Kpa |
| Field of view size |
121,93mm |
| Breakage resistance measurement range | 250〜5600kpa. |
| Inner diameter of upper clamp ring bore | ∮31.5 ± 0.05mm |
| Inner diameter of lower clamp ring hole | ∮31.5 ± 0.05mm |
| Film thicknes | Thickness of the central convex part 2.5 mm |
| Resolving power | 1 kpa |
| Accuracy | ±0.5%fs |
| Pressing speed | 170 ± 15ml/min |
| Specimen clamping force | >690kpa |
| Dimensions | 445,425,525mm(W*D,H) |
| Weight of the machine | 50kg |
| Power | 120W |
| Power supply voltag | AC220± 10%,50Hz |
Product Features:
This product adopts advanced microcomputer detection and control system and digital signal processing technology to ensure the accuracy of the test data, the first to use a large screen LCD graphic Chinese character display and touch screen technology friendly menu-type man-machine interface, easy to operate, with real-time calendar and clock, with power-down protection test data can be saved by the power-down and double-page display of the last 99 test records with a fast, high-quality micro-printer with a complete detailed The test data report is complete and detailed. Applicable to all kinds of cardboard and leather, cloth and leather, such as breaking strength test.
